Getting Started with Google Maps

Installation

npm install @map-gesture-controls/google-maps @googlemaps/js-api-loader

You also need a Google Maps API key with the Maps JavaScript API enabled. See Google's guide for details.

For TypeScript support, install the type definitions:

npm install -D @types/google.maps

Loading the Google Maps API

Use @googlemaps/js-api-loader to load the Maps JavaScript API before creating a map:

import { Loader } from '@googlemaps/js-api-loader';

const loader = new Loader({
  apiKey: 'YOUR_API_KEY',
  version: 'weekly',
});

const { Map } = await loader.importLibrary('maps');

Minimal working example

import { Loader } from '@googlemaps/js-api-loader';
import { GestureMapController } from '@map-gesture-controls/google-maps';
import '@map-gesture-controls/google-maps/style.css';

// 1. Load the Google Maps API
const loader = new Loader({ apiKey: 'YOUR_API_KEY', version: 'weekly' });
const { Map } = await loader.importLibrary('maps');

// 2. Create your Google Maps instance (mapId enables vector maps for rotation)
const map = new Map(document.getElementById('map')!, {
  center: { lat: 52.37, lng: 4.9 }, // Amsterdam
  zoom: 10,
  mapId: 'YOUR_MAP_ID',
});

// 3. Create the gesture controller
const controller = new GestureMapController({ map });

// 4. Start from a user gesture (browsers require a user interaction
//    before granting webcam access)
document.getElementById('start-btn')!.addEventListener('click', async () => {
  await controller.start();
});

document.getElementById('stop-btn')!.addEventListener('click', () => {
  controller.stop();
});

Your HTML needs a map container and buttons:

<div id="map" style="width: 100%; height: 100vh;"></div>
<button id="start-btn">Start gesture control</button>
<button id="stop-btn">Stop</button>

API key and Map ID setup

You need two things from the Google Cloud Console:

1. API key -- go to Keys & Credentials, create a key with the Maps JavaScript API enabled
2. Map ID -- go to Map Management, create a Map ID with the Vector map type (required for rotation support)

Local development

Create a .env file in your project root (already in .gitignore):

VITE_GOOGLE_MAPS_API_KEY=your_api_key_here
VITE_GOOGLE_MAPS_MAP_ID=your_map_id_here

Then reference them in your code:

const loader = new Loader({
  apiKey: import.meta.env.VITE_GOOGLE_MAPS_API_KEY,
  version: 'weekly',
});

const { Map } = await loader.importLibrary('maps');

const map = new Map(document.getElementById('map')!, {
  center: { lat: 52.37, lng: 4.9 },
  zoom: 10,
  mapId: import.meta.env.VITE_GOOGLE_MAPS_MAP_ID,
});

Restrict the API key to http://localhost:* for local use.

Production

Create a separate API key restricted to your production domain:

• HTTP referrer restriction: yourdomain.com/*
• API restriction: Maps JavaScript API only
• Set a daily quota cap

The same Map ID can be used for both local and production.

Why is a Map ID needed?

The mapId enables Google's vector map renderer (WebGL-based). Without it, Google Maps uses raster tiles, which do not support rotation via heading. Pan and zoom work without a Map ID, but rotation requires one.

User-gesture requirement

Browsers enforce a policy that getUserMedia() (webcam access) can only be called in response to a user interaction such as a button click. Calling controller.start() directly on page load will throw a NotAllowedError. Always wire start() to a click handler.

Model loading

start() triggers a one-time download of the MediaPipe hand landmarker WASM module and model weights (~10 MB combined). Subsequent calls to start() after stop() reuse the already-loaded model and are nearly instant.

Differences from OpenLayers

The gesture controller API is identical between adapters. The only differences are:

• You import from @map-gesture-controls/google-maps instead of @map-gesture-controls/ol
• The map property in GestureMapControllerConfig expects a google.maps.Map instead of an ol/Map
• No coordinate projection needed: Google Maps uses { lat, lng } directly

All configuration (webcam overlay, gesture tuning) is shared. See Configuration for the full reference.

Next steps

• Configuration: full reference for webcam and tuning options
• Gestures: how gestures are classified and tuned
• Examples: copy-pasteable recipes
• API Reference: full API documentation
